| CPU |
LGA1366 Intel Core i7シリーズ |
| QPI |
4.8GT/s 6.4GT/s |
| チップセット |
North Bridge Intel X58 Express
South Bridge Intel ICH10R |
| メモリ |
6x DDR3 2100+/1333/1066/800MHz |
| サウンド |
Realtek ALC889A HD Audio |
| LAN |
1x Realtek 8111D 10/100/1000 Mbit |
| 拡張スロット |
2x PCI-Express2.0(x16)/1x PCI-Express x8/1x PCI-Express x4/1x PCI-Express x1/2x PCI(32bit) |
| ストレージ |
ICH10R：6x SATA2(3Gb/s) RAID 0/1/5/10
GIGABYTE SATA2：2x SATA2(3Gb/s) RAID 0/1 1xIDE |
| IEEE1394 |
up to 3 IEEE1394a port |
| USB |
12x USB(8 on the back panel/4 via the brackets) |
| Internal I/O |
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x floppy disk drive connector
1 x IDE connector
8 x SATA 3Gb/s connectors
1 x CPU fan header
3 x system fan headers
1 x power fan header
1 x North Bridge fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF Out header
2 x USB 2.0/1.1 headers
2 x IEEE 1394a headers
1 x power LED header
1 x chassis intrusion header
1 x power switch
1 x reset switch |
| Back Panel |
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x coaxial S/PDIF Out connector
1 x optical S/PDIF Out connector
1 x IEEE 1394a port
1 x clearing CMOS switch
8 x USB 2.0/1.1 ports
1 x RJ-45 ports
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone) |
| H/W Monitoring |
System voltage detection
CPU/System/North Bridge temperature detection
CPU/System/Power fan speed detection
CPU overheating warning
CPU/System/Power fan fail warning
CPU/System fan speed control (Note 5) |
| BIOS |
2 x 8 Mbit flash
Use of licensed AWARD BIOS
Support for DualBIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b |
